Training CNN¶
LeNet-5 on MNIST¶
This practical example is based on the LeNet-5 architecture and the MNIST dataset. Note that we do not use the torchvision's ImageFolder dataset class and we do not move any files from local PC to Puhti like shown in the Preparing Data for Training section. Why? To make sure that the example script doesn't show 99 % correct answer to University course project. You need to implement that portion yourself.
Accessing the example files¶
The example files are located in the scripts directory of this repository. You can find a link to the Github repository in the top right corner of the page. Look for icon. Either clone the repository or download the specific files you need. The example files are:
Copying files to Puhti¶
Note
The latter command assumes you have configured your .ssh/config file to have an alias for Puhti. If you haven't, you can use the full command:
Using LOCAL_SCRATCH in Python¶
Whether you use MNIST downloader or ImageFolder, how you use the LOCAL_SCRATCH environment variable is the same. The os module in Python can be used to read environment variables. This is implemented in the lenet.py script, but is also demonstrated below for quick reference:
import os
# ...
DATA_PATH = os.environ.get("LOCAL_SCRATCH", "./data")
DATA_PATH = os.path.expandvars(DATA_PATH)
print(f"Using data path: {DATA_PATH}")
# ...
trainset = datasets.MNIST(
DATA_PATH, download=True, train=True, transform=train_transform
)
Running the job¶
This should start to feel familiar by now. Instead of running anything in the login node, you add the script to the chosen partition's queue. The choices are made in the Slurm script, which is lenet.sh in this case.
The lenet.sh script can be found in the repo, as mentioned above, but it's contents are shown below for quick reference. You will need to change the --account flag to match your project ID.
#!/bin/bash
#SBATCH --job-name=lenet_mnist_v001
#SBATCH --account=project_CHANGE_ME
#SBATCH --partition=gputest
#SBATCH --ntasks=1
#SBATCH --nodes=1
#SBATCH --cpus-per-task=10
#SBATCH --mem=64G
#SBATCH --time=00:14:59
#SBATCH --gres=gpu:v100:1,nvme:32
module purge
module load pytorch
# If you would be using ImageFolder, you would have to:
# unzip -q $PROJECTPATH/data/mnist.zip -d $LOCAL_SCRATCH
srun python lenet.py
Using the Model¶
The lenet.py script trains a simple LeNet-5 model on the MNIST dataset and stores it to models/MNIST_make_your_own_versioning_stragegy.pth. Now you can either:
- Implement an inference script and run it on Puhti, or
- Download the model to your local machine and run inference there.
The option 2 is easy and, assuming that you own a GPU-enabled machine (like Nvidia RTX 3060 or similar), typical assignment-scale models should run fine on your local machine. Training requires more resources than inference. To copy the model to your local machine, you can use scp again:
# A variable is created here to keep code lines shorter
MODELNAME=MNIST_make_your_own_versioning_stragegy.pth
MODELPATH=$PROJECTPATH/lenet/models/$MODELNAME
# Copy the model to local machine
scp puhti:$MODELPATH ./models/
Why the funky file name?
The file name is intentionally verbose to encourage you to implement your own versioning strategy for your models. You need to know what was the learning rate, batch size, and other hyperparameters for the model you are using. This is especially important when you start to experiment with different architectures and hyperparameters. You can use tools like MLflow or Weights & Biases to track your experiments, or simply maintain a well-structured directory and file naming convention plus potentially an Excel sheet to track your experiments.
Extra Tips and Resources¶
How to Handle Python Packages¶
What packages are in the module?¶
The pytorch module on Puhti contains a lot more than just PyTorch. It also contains many common dependencies, such as torchvision, torchaudio, and torchtext. You can check the exact content of the module by running:
Installing a new package¶
In case you need additional packages, you need some extra steps. A recommended method here is a virtual environment. Check the Using Python on CSC supercomputers. How will you know if you need additional packages? You will find out when you run the script and it throws an error about a missing package. Read the slurm-[jobid].out file to see the error message.
module load pytorch
which python
# Out: /appl/soft/ai/wrap/pytorch-2.9/bin/python3
python -m venv --system-site-packages .venv
source .venv/bin/activate
pip install cowsay
cowsay -t "Miau"
This will print out:
Warning
Your pip cache dir is located in your home directory, which has a very limited quota. If you install new packages, you may want to look into guide: How to avoid Python pip cache filling up my home directory
Now, in order to use this in your Slurm job, you will need to call to correct Python executable in your Slurm script:
Info
If you have a lot of dependencies, especially some that contains large files, you may want to look into using a container instead. Guide at CSC's Apptainer containers is a good starting point.
You don't need to build everything from scratch. Running module show pytorch reveals that pytorch module on Puhti is e.g. /appl/soft/ai/wrap/pytorch-2.9/container.sif image. You can follow CSC's Example: Extending a local image to build your own image on top of that, adding only the packages you need as layer on top of the existing image. This will save you a lot of time and effort, while also giving you the flexibility to add whatever packages you need.
How to Monitor GPU Usage¶
After the Job¶
Use seff <jobid> to check CPU and GPU usage stats after the job completes.
During the Job¶
A quick and dirty way to monitor GPU usage during a job is to run nvidia-smi in a loop on the compute node. You can do this by adding the following line to your slurm script:
# Find nodename
squeue -u $USER
# One-time SSH into the node to check GPU status
ssh <nodename> nvidia-smi
This tiny LeNet-5 model consumes very little GPU memory:
Sun Feb 15 10:55:22 2026
+---------------------------------------------------------------------------------------+
| NVIDIA-SMI 535.288.01 Driver Version: 535.288.01 CUDA Version: 12.2 |
|-----------------------------------------+----------------------+----------------------+
| GPU Name Persistence-M | Bus-Id Disp.A | Volatile Uncorr. ECC |
| Fan Temp Perf Pwr:Usage/Cap | Memory-Usage | GPU-Util Compute M. |
| | | MIG M. |
|=========================================+======================+======================|
| 0 Tesla V100-SXM2-32GB On | 00000000:89:00.0 Off | 0 |
| N/A 35C P0 79W / 300W | 597MiB / 32768MiB | 32% Default |
| | | N/A |
+-----------------------------------------+----------------------+----------------------+
+---------------------------------------------------------------------------------------+
| Processes: |
| GPU GI CI PID Type Process name GPU Memory |
| ID ID Usage |
|=======================================================================================|
| 0 N/A N/A 1149299 C ...soft/ai/wrap/pytorch-2.9/bin/python 594MiB |
+---------------------------------------------------------------------------------------+
Tip
A better option would be to use e.g. torch.profiler to log GPU usage stats during the job. This is a bit more work to set up, so we won't cover it in this guide. You could even place these to MLflow, if you want true visibility into your training runs.
Further Reading¶
Note that the guide below will most likely 100% match your use case. You will need to adapt the code and commands to your needs. The guide is meant to be a starting point and a reference for you to build on top of. Check the CSC documentation for more details and examples:
- You will find example
.pyfiles at gh:CSCfi/machine-learning-scripts/tree/master/examples - And Slurm files at gh:CSCfi/machine-learning-scripts/tree/master/slurm
CSC has a very through documentation. Use it. They have also very helpful staff that can be contacted via email or by attending their Zoom sessions: CSC Research Support Coffee – Every Wednesday at 14:00 Finnish time
